Adjustable Fillet Weld Gauge
$100.50
Measures:
- Fillet weld leg lengths from 1/8″ to 1″ in 1/32″ increments
- Unequal legged fillet welds
- Desired throat thickness of fillet welds
Description
Enhance welding precision with G.A.L.’s Adjustable Fillet Weld Gauge. Versatile design checks 15 sizes of fillet welds, equal or unequal. Measure leg lengths from 1/8″ to 1″ in 1/32″ increments, unequal legged fillets, and throat thickness with ease.
Measures:
- Fillet weld leg lengths from 1/8″ to 1″ in 1/32″ increments
- Unequal legged fillet welds
- Desired throat thickness of fillet welds
Additional information
| Weight | 0.15 lbs |
|---|---|
| Dimensions | 4 × 3.5 × 0.5 in |
| Brand | G.A.L. Gage Co. |
