PosiPen
$265.00
Equipped with the smallest probe of any magnetic pull-off gauge, the PosiPen is a miniature (5.5″ long) gauge that measures the thickness of any non-magnetic coating applied to a ferrous substrate.
Available on backorder
Description
PosiPen
Equipped with the smallest probe of any magnetic pull-off gauge, the PosiPen is a miniature (5.5″ long) gauge that measures the thickness of any non-magnetic coating applied to a ferrous substrate. The gauge is ideal for measuring coating thickness (0.25 -20 mils; 5-500 microns) on small, hot (up to 450°F) or difficult access surfaces. The gauge can be used in any position, and has a triple, color-coded, dual (mils/microns) indicator scale for measurements taken vertically, horizontally or overhead. Perfect for measuring the thickness of the coating on or between the ribbing on rebar. Comes with a leather pouch. Accuracy is +/- 10% of the reading, traceable to NIST. Made in the USA.
Manufacturer: DeFelsko
Additional information
| Weight | 0.3000 lbs |
|---|---|
| Brand |
Defelsko |
| Readout Type |
Analog (Type 1) |
| Substrate |
Ferrous Metals |
| Test Method |
ASTM B499 ,ASTM D7091 |
